Igbt Power Device With Unique Control Mode Improves The Reliability Of The Machine
Closed Loop Feedback Control,constant Voltage Output, Workable Under Minor Voltage Fluctuations Of Upto ±15%
Adjustable Welding Voltage And Current
High Successful Rate Of Arc Ignition
High Inverter Frequency Greatly Reduces The Volume And Weight
Great Reduction In Magnetic And Resistance Loss Leads To Enhancing Of The Welding Efficiency And Saves Power.
Switching Frequency Is Betond Audio Range, Which Almost Eiminates Noise Pollution.
Upto 55-60% Savings On Labour And Energy
| PARAMETERS | MIG 300L | MIG 301 | MIG 300 |
|---|---|---|---|
| VOLTAGE (V) | 240/415V | 1P AC230C±15% | AC 415V±15% |
| FREQUENCY (HZ) | - | - | 50/60 |
| RATED INPUT CURRENT (A) | 44.5/25.7A | 45 | 13 |
| OUTPUT CURRENT (A) | 250A | - | 50-300 |
| OUTPUT VOLTAGE(V) | 26.5V | - | 16.5-26.5 |
| RATED POWER SUPPLY CAPACITY (KVA) | - | 10.4 | - |
| RECOMMENDED FUSE CAPACITY (A) | - | 70 | - |
| MMA WELDING CURRENT RANGE (A) | - | 10-301 | - |
| MIG CURRENT RANGE (A) | - | 25-301 | - |
| MIG VOLTAGE RANGE (V) | - | 11-29 | - |
| NO-LOAD VOLTAGE(/V) | - | 54 | - |
| WIDE FEED SPEED RANGE (M/MIN) | 2-15 | 1.5-16 | 2.5-18 |
| RATED DUTY CYCLE (%) | 60 | 35 | 60 |
| EFFICIENCY (%) | 93 | 85 | 85 |
| POWER FACTOR | - | 0.75 | - |
| PROTECTION CLASS | IP21S | IP21S | IP21 |
| INSULATION CLASS | F | F | F |
| DIMENSIONS (MM) | 705x405x626 | 880x296x616 | 705x405x626 |
| WEIGHT (KG) | - | 25 | 28 |
| PARAMETERS | MIG 300L | MIG 301 | MIG 300 |
|---|---|---|---|
| WIRE DIAMETER | 0.8-1.0 | 0.6-1.0 | 0.8 |
| CURRENT RANGE | 50-300 | 25-250 | 50-300 |
