COMPATIBLE WITH HIGH EFFICIENY AND HIGH DEPOSITION RAТЕ
Processes
CC SAW
CV SAW
CARBON ARC GOUGE
MMA
Package Includes
Inverter Power Source
Track
Welding Cable, 10m
Earth Clamp, 6m
Control Cable , 10m
Welding Carriage/Tractor
Optional Accessories
Helmet
Carbon Arc Gouge
Features
Equip Auto Start Interface To Special Machine
Analog Keys And Rotary Knobs For Convenient Operation
Intelligent Energy Saving Mode As The Machine Stops Working For More Than 5 Minutes
Unique Control Circuit To Balance Two Side's Output Current And Voltage
Contact Pad Stop Functions To Stop Auto Wire Feeding When Arrived At Designated Position
Startup Protection Circuit In Case Of Inrush Current
Tri-Proof Air Duct Design
| MODEL | INPUT VOLTAGE PHASE FREQUENCY | OUTPUT CURRENT VOLTAGE | AMPS INPUTS AT RATED OUTPUT | OUTPUT RANGE | DIMENSION MM | WEIGHT KG |
|---|---|---|---|---|---|---|
| MZ1000CV | 380V/3P/50-6-HZ | SAW:1000A/44V/60% 775A/44V/100% / MMA: 1000A/44V/40% 775A/44V/100% / GOUGE: 1000A/44V/40% 775A/44V/100% | 77.2@1000A 100-1000A/98V | TIG:10-210A/68V(DC) / MMA:10-160A/60A | 760X380X800 | 85 |
| MZ1250CV | 380V/3P/50-60HZ | SAW:1250A/44V/40% 800A/44V/100% / MMA:1250A/44V/40% 800A/44V/100% / GOUGE:1250A/44V/40% 800A/44V/100% | 130A@1250A 125-1250A/90V | TIG:12-300A/62V / MMA:15-240A/62A | 760X380X800 | 85 |
