MIG/Gasless, MIG, MMA Function
Advanced Igbt Technology
Synergic
Low Splash
Intelligent Protection- Over- Current,over Voltage, Over Heating Protection
Compatible to Use With 5 Kg Spool , Flux Core Wire
60% Duty Cycle and Contineous Welding for Long Time
Equipped With Lcd Screen to Clearly Display Welding Parameters and Status
Voltage Micro-adjustable.
| PARAMETERS | MIG 205 | MIG 160 |
|---|---|---|
| Input voltage(V) | 240 | 240 |
| Input current(A) | 23.6 | 16 |
| Output current (A) | 160 | 120 |
| Output voltage (V) | 22 | 20 |
| Duty cycle (%) | 60 | 60 |
| Efficiency (%) | 93 | 93 |
| Feeding Speed | 2-15M/MIN | 2-13M/MIN |
| Protection Class | F | F |
| Insulation Class | IP21 | IP21 |
| Dimensions (MM) | 465x350x380 | 350x300x250 |
| PARAMETERS | MIG 205 | MIG 160 |
|---|---|---|
| Wire Diameter | 0.8 | 0.8 |
| Current Range (A) | 30-160 | 30-160 |
