Advanced Igbt Inverter Technology Delivers Superior Tig Performance. Digital Instrument For The Welding Current
Auto-protection Against Over-voltage, Over Current And Over Heated High Performance Ensure Continuous And Stable Operation Of Welder
Consists Of Functions Like Arc Initiation Current,arc Stop Current,welding Currentand Basic Value Current
Digital Meter to Pre - Set and Display Welding Current
Upto 55-60% Savings On Labour And Energy
It Can Used For Welding Of Stainless Steel,carbon Steel,copper And Other Colour Metals As Well
The Machine Is Also Compatible And Can Be Used For Traditional Electric Welding
Offers Best In Class Finishing And Efficiency
Labour Savings Of Upto 55%
Power Savings Of Upto 55%
| PARAMETERS | TIG 400IJ |
|---|---|
| POWER VOLTAGE(V) | 3P AC415V±15% |
| FREQUENCY (HZ) | 50/60 |
| RATED INPUT CURRENT (A) | 25.3 |
| NO-LOAD VOLTAGE (V) | 80 |
| OUTPUT CURRENT (A) | 10-400 |
| RATED WORKING VOLTAGE (V) | 10.4-26(TIG) 20.4-35(MMA) |
| DUTY CYCLE (%) | 60 |
| NO-LOAD LOSS (W) | 100 |
| ARCING WAY | HF |
| EFFICIENCY (%) | 85 |
| POWER FACTOR | 0.93 |
| INSULATION GRADE | H |
| HOUSING PROTECTION GRADE | IP21S |
| WEIGHT(KG) | 34 |
| DIMENSIONS(MM) | 560x300x550 |
| PULSE FREQUENCY (HZ) | 0.5-15(LF) 14-450(MF) |
| CURRENT ASCENDING TIME(S) | 0-10 |
| CURRENT DESCENDING TIME(S) | 0-10 |
| BASIC VALUE CURRENT (A) | 10-400 |
| ARC INITIATION CURRENT (A) | 10-400 |
| ARC STOP CURRENT (A) | 10-400 |
| GAS POST FLOW TIME (S) | 1-10 |
| PULSE DUTY (%) | 10-90 |
| PARAMETERS | TIG 400IJ |
|---|---|
| PLATE THICKNESS(MM) | 2-20 |
| WELDING ROD/CARBON ROD DIAMETER | 1.6-5.0 |
| CURRENT RANGE(A) | 20-400 |
