Multi - Functional : Pulse TIG AC / DC and MMA Function
2T / 4T and Repeat Function
Up Slope and Down Slope Function Adjustable
Pluse Frequency 0 - 5HZ Adjustable
Pulse Frequency and Pulse Width Adjustable
Start Current, Base Current ,Peak Current and Crater Cureent Adjustable
Adopt Advanced Module IGBT Technology
Aluminum Products
Decoration
Light & Medium Fabrication
Pipes & High Pressure Vessels
Construction
| PARAMETERS | TIG 500P AC/DC |
|---|---|
| Power Voltage (V) | 3P 415v±15% |
| Frequency (Hz) | 50/60 |
| Rated Input Current (A) | MMA-29.5/tig-21 |
| Efficiency (%) | MMA-45/tig-31.5 |
| Rated Duty Cycle (%) | 85 |
| Basic Value Current (A) | 60 |
| Output No-load Voltage (V) | 10-510 |
| Output Rated Voltage (V) | 70 |
| Arc Start Current (A) | 40/30 |
| Arc Frequency | 10-500 |
| Duty Cycle (%) | 20-100 |
| Arc End Current (A) | 85 |
| Arc Striking Mode | 10-500 |
| Insulation Class | HF |
| Insulation Grade | F |
| Protection Mode | IP21S |
| Cooling Mode | Air Cooling |
| Dimensions (MM) | 765x330x750 |
| PARAMETERS | TIG 500P AC/DC |
|---|---|
| PLATE THICKNESS(MM) | 1.0-20.0 |
| CURRENT RANGE(A) | 20-500 |
