Advanced Tubular Igbt Technology
Compressor Inside
220/380v Dual Voltage Input
Cut and Mma Dual Function
Non-stop Welding for 2.5 and 3.15 Mm Electrode
2t/4t. Gas Purge and Gas Source Function Select-able
Post-flow Adjustable.
Easy Arc Adjustable
Easy Arc Ignition With Hf for Cutting
Smooth and Neat Cutting Surface
| PARAMETERS | CUT 80S | CUT 71 IGBT | CUT 70 IGBT |
|---|---|---|---|
| Input voltage (V) | 240/415V | 240V | 415V |
| Input current (A) | 58/15A | 51A | 13.3A |
| Output current (A) | 70A | 70A | 70A |
| Output voltage (V) | 108V | 108V | 108V |
| Duty cycle (%) | 60 | 60 | 60 |
| Efficiency (%) | 93% | 93% | 93% |
| Protection class | F | F | F |
| Insulation class | IP21 | IP21 | IP21 |
| Dimension (MM) | 560x365x460 | 610x360x425 | 610x360x425 |
| PARAMETERS | CUT 80S | CUT 71 IGBT | CUT 70 IGBT |
|---|---|---|---|
| PLATE THICKNESS (MM) | 2.0-16.0 | 2.0-16.0 | 2.0-18.0 |
| ARCHING WAY | UNTOUCHED | UNTOUCHED | UNTOUCHED |
| CURRENT RANGE (A) | 15-70 | 20-80 | 15-70 |
