FULL FUCTION AND ALSO EXPERT IN WELDING ALUMINUM
Processes
DC TIG
AC TIG
PULSE TIG
MMA
Remote Control
Package Includes
Inverter Power Source
TIG Torch, 4m
Earth Clamp, 3m
Tungsten Electrode, Cerium Tungsten
Optional Accessories
Electrode Holder, 3m
Foot control Pedal
Helmet
Features
AC/DC Selectable
Pulse Frequency Pulse Width Adjustable
Ac Balance Adjustable
2T/4T
Post-Flow Adjustable
Down-slope Adjustable
Start Current And Crater Current Adjustable
Tri-proof Air Duct Design
| MODEL | INPUT VOLTAGE PHASE FREQUENCY | OUTPUT CURRENT VOLTAGE | AMPS INPUTS AT RATED OUTPUT | OUTPUT RANGE | DIMENSION MM | WEIGHT KG |
|---|---|---|---|---|---|---|
| TIG 250P AC/DC | 220V/1P/50-60Hz | TIG: 210A/18.4V/30%@40*C 150A/16V/100%@40*C / MMA:160A/26.4V/30%@40*C 120A/24.8V/100%@40*C | TIG: 36.5A@210A / MMA:35.4A@160A | TIG:10-210A/68V(DC) / MMA:10-160A/60A | 476X340X402 | 20 |
| TIG 315P AC/DC | 380V/3P/50-60Hz | TIG: 210A/18.4V/30%@40*C 150A/16V/100%@40*C / MMA:160A/26.4V/30%@40*C 120A/24.8V/100%@40*C | TIG: 17.2A@300A / MMA:15.4A@240A | TIG:12-300A/62V(DC) / MMA:15-240A/62A | 609X332X622 | 36 |
