GOOD HAND IN WELDING HEAT CONTROL
Processes
DC TIG
PULSE TIG
MMA
Package Includes
Inverter Power Source
TIG Torch, 4m
Earth Clamp, 3m
Tungsten Electrode, Cerium Tungsten
Optional Accessories
Electrode Holder, 3m
Water Cooler
Helmet
Features
Pulse Frequency Adjustable
2T/4T
Post-Flow Adjustable
ARC Force Adjustable
Peak Current And Background Current Adjustable
| MODEL | INPUT VOLTAGE PHASE FREQUENCY | OUTPUT CURRENT VOLTAGE | AMPS INPUTS AT RATED OUTPUT | OUTPUT RANGE | DIMENSION MM | WEIGHT KG |
|---|---|---|---|---|---|---|
| TIG 200M | 220V/1P/50-60Hz | TIG: 200A/18V/60% 155A/16.2V/100% / MMA: 180A/27.2V/60% 140A/25.6V/100% | TIG: 28A@200A / MMA: 378@180A | TIG:10-200A/56V / MMA:30-180A/56A | 432X204X302 | 13 |
